Intel Core Ultra. Eight 2.5G ports. No fan.
Built for firewall, VPN, router and network-server roles. Runs Windows 10/11, Linux, pfSense and iKuai.
Keep scrolling. The layers below come straight from the factory CAD.
Core Ultra 5 125U or Core Ultra 7 155U: 12 cores, 14 threads, plus the Intel AI Boost NPU.
Two DDR5-5600 SODIMM slots. One M.2 2280 NVMe (PCIe 4.0 ×4) plus a 2.5-inch HDD/SSD bay.
M.2 E-key for Wi-Fi, M.2 B-key for 4G/5G with external SIM slot. HDMI, DP and Type-C, up to 4096 × 2160 at 60 Hz.
The processor sits on top of the mainboard, directly under the aluminium lid.
With no fan inside, the enclosure itself carries heat away from the 15 W processor.
Heat spreads across the finned top and leaves by natural air flow. Rated −20 to 50 °C with an industrial SSD.
170 × 140 × 58 mm, 1.36 kg. Fit it with the optional side wall-mount kit (179 × 80 mm holes) or the included VESA 75/100 bracket.
Regional supply and technical support from IWILL Technology. Tell us the quantity and configuration and we reply with a quote.
| Processor | Intel Core Ultra 5 125U / Ultra 7 155U, 15 W, Intel AI Boost NPU |
|---|---|
| Memory | 2 × DDR5 5600 SODIMM, max. 64 GB |
| Storage | 1 × M.2 2280 M-key NVMe (PCIe 4.0 ×4), 1 × 2.5" HDD/SSD |
| Ethernet | 8 × 2.5G: 1 × Intel i226-LM (vPro, LAN1), 7 × Intel i226-V |
| Front I/O | 4 × USB 3.2, Type-C (DP/USB 3.2), HDMI, DP, RJ45 console, SIM slot |
| Wireless | M.2 2230 E-key (Wi-Fi), M.2 3052/2242 B-key (4G/5G) |
| Security | TPM 2.0, watchdog 0–255 levels |
| Power | DC 12 V |
| Environment | 0–40 °C (commercial HDD), −20–50 °C (industrial SSD), 5–95 % RH non-condensing |
| Size / weight | 170 × 140 × 58 mm, 1.36 kg |
| Certification | CE, CCC, FCC Class A, RoHS |
Specifications subject to change
